Bidirectional broadside arrays
28 CompleTech part numbers. Pick the frequency band, compare the specifications, request a quote.
Two opposite directions at once: the CAB2 bidirectional broadside (6 dBi) and the CAB4 bidirectional stacked broadside (9 dBi), which CompleTech lists with "field adjustable pattern, optional beam tilting" (ComAnt catalog, pp. 20 and 21).
When you order, add the connector to the part number: -N, -TNC, -BNC, -SMA or -7/16 (CompleTech's product list). We confirm it on the quote.
No listed part matches. Send us the frequency or the system and we will find it.
Request a quote83–88 MHz 2
-
CA85B2Bidirectional broadside- Frequency
- 83-88 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 1235 mm
- Weight
- 2920 g
- Wind load
- 168 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA85B4Bidirectional stacked broadside- Frequency
- 83-88 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 5315 mm
- Weight
- 6460 g
- Wind load
- 336 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
135–145 MHz 2
-
CA140B2Bidirectional broadside- Frequency
- 135-145 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 985 mm
- Weight
- 2260 g
- Wind load
- 126 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA140B4Bidirectional stacked broadside- Frequency
- 135-145 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 3270 mm
- Weight
- 4970 g
- Wind load
- 252 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
144–156 MHz 2
-
CA150B2Bidirectional broadside- Frequency
- 144-156 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 930 mm
- Weight
- 2200 g
- Wind load
- 120 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA150B4Bidirectional stacked broadside- Frequency
- 144-156 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 3065 mm
- Weight
- 4800 g
- Wind load
- 240 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
154–166 MHz 2
-
CA160B2Bidirectional broadside- Frequency
- 154-166 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 880 mm
- Weight
- 2110 g
- Wind load
- 114 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA160B4Bidirectional stacked broadside- Frequency
- 154-166 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 2875 mm
- Weight
- 4610 g
- Wind load
- 228 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
163–177 MHz 2
-
CA170B2Bidirectional broadside- Frequency
- 163-177 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 840 mm
- Weight
- 2095 g
- Wind load
- 110 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA170B4Bidirectional stacked broadside- Frequency
- 163-177 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 2710 mm
- Weight
- 4565 g
- Wind load
- 220 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
221–239 MHz 2
-
CA230B2Bidirectional broadside- Frequency
- 221-239 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 650 mm
- Weight
- 1890 g
- Wind load
- 90 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA230B4Bidirectional stacked broadside- Frequency
- 221-239 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 2050 mm
- Weight
- 4120 g
- Wind load
- 180 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
326–353 MHz 2
-
CA340B2Bidirectional broadside- Frequency
- 326-353 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 485 mm
- Weight
- 1690 g
- Wind load
- 72 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA340B4Bidirectional stacked broadside- Frequency
- 326-353 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 1415 mm
- Weight
- 3670 g
- Wind load
- 144 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
336–364 MHz 2
-
CA350B2Bidirectional broadside- Frequency
- 336-364 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 400 mm
- Weight
- 1690 g
- Wind load
- 72 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA350B4Bidirectional stacked broadside- Frequency
- 336-364 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 1280 mm
- Weight
- 3670 g
- Wind load
- 144 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
365–395 MHz 2
-
CA380B2Bidirectional broadside- Frequency
- 365-395 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 445 mm
- Weight
- 1660 g
- Wind load
- 70 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA380B4Bidirectional stacked broadside- Frequency
- 365-395 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 1285 mm
- Weight
- 3600 g
- Wind load
- 140 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
380–410 MHz 2
-
CA400B2Bidirectional broadside- Frequency
- 380-410 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 430 mm
- Weight
- 1630 g
- Wind load
- 68 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA400B4Bidirectional stacked broadside- Frequency
- 380-410 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 1240 mm
- Weight
- 3530 g
- Wind load
- 136 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
405–440 MHz 2
-
CA420B2Bidirectional broadside- Frequency
- 405-440 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 415 mm
- Weight
- 1605 g
- Wind load
- 66 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA420B4Bidirectional stacked broadside- Frequency
- 405-440 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 1165 mm
- Weight
- 3465 g
- Wind load
- 132 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
440–475 MHz 2
-
CA450B2Bidirectional broadside- Frequency
- 440-475 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 390 mm
- Weight
- 1590 g
- Wind load
- 64 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA450B4Bidirectional stacked broadside- Frequency
- 440-475 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-/TNC-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 1080 mm
- Weight
- 3430 g
- Wind load
- 128 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
830–890 MHz 2
-
CA860B2Bidirectional broadside- Frequency
- 830-890 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 270 mm
- Weight
- 1480 g
- Wind load
- 50 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA860B4Bidirectional stacked broadside- Frequency
- 830-890 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 625 mm
- Weight
- 3180 g
- Wind load
- 100 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
880–960 MHz 2
-
CA930B2Bidirectional broadside- Frequency
- 880-960 MHz
- Gain
- 6 dBi
- Polarization
- vertical
- Connector
- N-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 255 mm
- Weight
- 1455 g
- Wind load
- 50 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 69º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB2 family, ComAnt catalog (March 2026), page 20.
-
CA930B4Bidirectional stacked broadside- Frequency
- 880-960 MHz
- Gain
- 9 dBi
- Polarization
- vertical
- Connector
- N-female
- VSWR
- <1.5
More specifications
- Radome
- ABS/FG, PU foam
- Radiator
- copper
- Mounting
- Ø 35-60
- Length
- 587 mm
- Weight
- 3125 g
- Wind load
- 100 N @ 150 km/h
- Horizontal beamwidth (−3 dB)
- 71º*
- Vertical beamwidth (−3 dB)
- 27º*
- Front-to-back
- 0 dB*
- Temperature
- -40ºC - +80ºC*
- IP rating
- 67*
* From CompleTech's datasheet for the CAB4 family, ComAnt catalog (March 2026), page 21.
Need it built, not just bought?
Our UL 508A panel shop in Brookfield, Wisconsin builds radio and telemetry enclosures: the radio, the lightning protection and the cabling, wired and tested. Build to print or PLC and control panels.
